μ PC8178TK
PIN CONNECTIONS
(Top View)
(Bottom View)
Pin No.
Pin Name
1
6
6
1
1
INPUT
2
GND
2
3
5
4
5
4
2
3
3
4
GND
OUTPUT
PIN EXPLANATION
5
6
GND
V CC
Pin
No.
1
Pin
Name
INPUT
Applied
Voltage
(V)
?
Pin
Voltage
Note
(V)
0.90
Function and Applications
Signal input pin. A internal
Internal Equivalent Circuit
matching circuit, configured with
resisters, enables 50 ? connection
over a wide band. This pin must
be coupled to signal source with
capacitor for DC cut.
2
3
GND
0
?
Ground pin. This pin should be
connected to system ground with
6
5
minimum inductance. Ground
pattern on the board should be
formed as wide as possible.
All the ground pins must be con-
nected together with wide ground
pattern to decrease impedance
defference.
4
4
OUTPUT
Voltage
as same
?
Signal output pin. This pin is de-
signed as collector output. Due to
2
as V CC
the high impedance output, this pin
through
should be externally equipped with
3
1
5
external
inductor
LC matching circuit to next stage.
For L, a size 1 005 chip inductor
can be chosen.
6
V CC
2.4 to 3.3
?
Power supply pin. This pin should
be externally equipped with bypass
capacitor to minimize its
impedance.
Note Pin voltage is measured at V CC = 3.0 V.
4
Data Sheet PU10063EJ02V0DS
